    Rs232 Or Usb 230v Rack Mount Ups 2kva 3kva Uninterrupted Power Supply

    Ask Lasest Price
    Brand Name : OEM/ODM
    Certification : CE
    Model Number : PMR2000S,PMR3000S
    Price : Negotiable
    Delivery Time : 3 weeks after down payment
    Payment Terms : TT or LC
    Supply Ability : 3000pcs/month
    • Product Details
    • Company Profile

    Rs232 Or Usb 230v Rack Mount Ups 2kva 3kva Uninterrupted Power Supply


    Rs232 Or Usb 230v Rack Mount Ups 2kva 3kva Uninterrupted Power Supply


    Quick Detail:


    1)Smart RS232(USB,SNMP OPTIONAL)

    2)Rated voltage: 220v/230v/240Vac or 110/120/120Vac

    3)Self-diagnosis system at ups start


    Perfect Application:
    Computer center, network center, communication system
    automatic control system data center or other critical systems.
    Main Features:
    High frequency and online double conversion
    Wide input voltage (110-285Vac or 65-148Vac)
    Self-diagnosis system at ups start
    Digital control technoloy and advanced PFC
    Output PF0.8,(0.9 optional)
    Lighting and surge protection 1050j
    Generator compatible
    Smart RS232(USB,SNMP OPTIONAL)
    EMI/RFI noise filter
    Overview
    With true double-conversion design, PowerMaster series provides powerful and overall protection to your sensitive devices. It can accept wider input voltage for harsh environment. It's perfect protection for your precisous servers and workstaiosn.
    Specifications
    ModelPMR02SPM3000S
    Capacity2KVA/1.6kW3KVA/2.4kW
    PhaseSingle
    Input voltage
    Input PFabove 0.98
    THDiless than 5%
    Rated voltage220v/230v/240Vac or 110/120/120Vac
    Input voltage rangeLow line transfer:176 VAC ± 3% @ 100% load
    130 VAC ± 3% @ 50% load
    85-148Vac( for 110/120/127Vac)
    Low line comback:188VAC ± 3% @ 100% load
    142 VAC ± 3% @ 50% load;
    100vac±5Vac(110/120/127Vac)
    High Line Transfer:286 ± 3%148Vac ± 3%(for 110/120/120vac);
    High Line Come Back:271 ± 3%;
    145Vac±5Vac(110/120/127Vac)
    Rated frequency50/60hz(auto sensing)
    Input frequency range46~54 Hz ◎ 50 Hz / 56~64 Hz ◎ 60 Hz
    By-pass input
    Input voltage range170VAC—270VAC±5V
    Frequency following range46~54 Hz ◎ 50 Hz / 56~64 Hz ◎ 60 Hz
    Recharge battery
    Floating charge voltage84VDC
    Recharging current1A(Rack batt.case)
    Battery
    Battery quantity6PCS*12Vdc*7AH6PCS*12Vdc*9AH
    AC output
    Power factor0.8
    Phasesingle
    Rated voltage220v/230v/240v+/-1.5%
    Frequency50/60hz
    Frequency stability±0.1HZ(battery inverter)
    Voltage stabilitywithin±1.5%( Static)
    Crest factor3:1(max)
    Wave distortionLinear load less 3%,Non-linear load less 5%;
    Over load ability30s when overload is 108%~150%;200ms above 150%;
    Transfer time0ms
    Alarm
    AC abnomalAlarm every 4 seconds
    Battery low voltageKeep alarm every 1 second
    OverloadKeep alarm every 0.5 second
    FailureKeep alarm
    System
    Efficiencyabove 87%
    DisplayLCD+LED
    ProtectionOutput short circuit , Overload , Output low voltage, Battery low voltage, Over-temperature etc.
    over-voltage protection,over-tempreture protection for charger PCB,and soft-start function for each function module.
    InfterfaceRS232(USB OPTIONAL)
    Working Temp.0~40℃
    Relative humidity0~90%( No coagulation)
    CoolingIntelligent speed-control Fan
    Input & outputSocket(Optional)
    Others
    Surge protectionIEC60664—1 Graded protection
    EMIEN 55022 Grade A
    ESDIEC 1000-4-2:Grade 3
    EFTIEC 1000-4-4:Grade 3
    RSIEC 1000-4-3:Grade 3
    SURGEIEC 1000-4-5:Grade 3
    Physical
    Weight(N/G)kgs25.0/28.028.0/31.0
    Unit Size510* 440 *132 mm(D*W*H)
    Packing Size640*570 *230 mm(D*W*H)
