12.8V 6AH Lithium Iron Battery With AGM Case

    Buy cheap 12.8V 6AH Lithium Iron Battery With AGM Case from wholesalers

    Buy cheap 12.8V 6AH Lithium Iron Battery With AGM Case from wholesalers
    • Buy cheap 12.8V 6AH Lithium Iron Battery With AGM Case from wholesalers
    • Buy cheap 12.8V 6AH Lithium Iron Battery With AGM Case from wholesalers

    12.8V 6AH Lithium Iron Battery With AGM Case

    Ask Lasest Price
    Brand Name : HRD /JUNLEE/OEM
    Model Number : 12.8V 7AH-250AH
    Certification : MSDS
    Price : 16-1000USD/PCS;
    Supply Ability : 1000PCS+/WEEK
    • Product Details
    • Company Profile

    12.8V 6AH Lithium Iron Battery With AGM Case

    12.8V 6AH Lithium Iron Battery


    Features:12.8V battery with AGM case

    ◆ Using the technology of lithium iron phosphate cell, superior safety, thousands of cycles, 100%DOD, under normal conditions

    ◆ Built-in automatic protection for over-charge, over discharge, over current and over temperature

    ◆ Maintenance free

    ◆ Internal cell balancing

    ◆ Lighter weight: About 40% ~50% of the weight of a comparable lead acid battery.



    Electrical Characteristics

    Nominal Voltage12.8V
    Nominal Capacity6Ah@0.2C
    Energy76.8Wh
    12.8V 6AH Lithium Iron Battery With AGM Case12.8V 6AH Lithium Iron Battery With AGM Case◆ Golf Cart70≤mΩ
    Cycle Life>2000 Cycles @ 0.2C Charge/Discharge at 100%DOD,End of Life 70% Capacity.
    12.8V 6AH Lithium Iron Battery With AGM Case12.8V 6AH Lithium Iron Battery With AGM Case12.8V 6AH Lithium Iron Battery With AGM Case≤3.5% per month at 25℃

    Standard Charge

    Charge Voltage14.6±0.2V
    Charge Mode(CC/CV)At 0℃~45℃ temperature, charged to 14.6V at a constant current of 0.2C5A, and then,changed continuously with constant voltage of 14.6V until the current was not more than 0.02C5A.
    Charger Current1.2A
    Max.Charge Current3A

    Standard Discharge

    Discharge Current1.2A
    Max. Continuous Current6A
    Max.Pulse Current20A(<3S)
    Disxcharge Cut-off Voltage10.0V

    Environmental

    Charge Temperature0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
    Disxcharge Temperature-20℃ to 60℃(-4℉ to 140℉) @60±25% Relative Humidity
    Storage Temperature0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
    Water Dust ResistanceIP55

    Mechanical

    Cell & MethodIFR32700 N60,4S1P
    Plastic CaseABS
    Dimension(L*W*H*TH)90*70*101*107mm
    WeightApprox. 0.75Kg
    TerminalF2


    Quality 12.8V 6AH Lithium Iron Battery With AGM Case for sale
